Anemometer Display

High resolution wind speed (0.1 m/s) and direction (1 degree) Anemometer

Temperature Resistant and moisture proof machanic design

7" high brightness LCD display









  Specifications
Display 7" TFT/480x234 pixels
Brightness Adjustment 9 Levels adjustable
Data Output NMEA0183 Wind speed and direction
NMEA port RS422 Output 2 pin NMEA A/B
Direction Accuracy +- 1 degree
Wind Range 0-359 degrees
Speed Accuracy 0.1 m/s
Speed Range 0-60 m/s
Startup Wind Speed =<1.2 m/s
Power Supply  24V DC (20-32V DC) 5W
Operation Temperature -15 to +55 degree C
Storage Temperature -20 to +70 degree C
Humidity  10-90 % relative, no condensation
Protection IP23
Sensor
Operating Temperature -15 to +85 degree C
Storage Temperature -20 to +85 degree C
Protection
IP56
Uten navn 1



Please click here to download brochure and CCS certificate
